We manufacture Sugar Syrup Storage & Mixing Tanks designed for Pharmaceutical, Food & Beverage, Confectionery and Industrial Applications. Our tanks ensure hygienic storage, uniform mixing, controlled heating and contamination-free handling of sugar syrup.
Manufactured using SS 304 / SS 316L with sanitary design, smooth internal finish and cGMP compliant fabrication suitable for sterile and clean processing environments.
| Parameter | Details |
|---|---|
| Capacity | 100 L to 10,000 L (Customized) |
| Material of Construction | SS 304 / SS 316L |
| Internal Finish | Mirror / Electro Polish (0.4 – 0.8 Ra) |
| External Finish | Matt / Mirror |
| Tank Type | Jacketed / Non-Jacketed |
| Insulation | Rockwool / Polyurethane Optional |
| Agitator | Top Mounted / Bottom Mounted |
| Mixing Type | Anchor / Turbine / Propeller |
| Heating System | Steam / Electrical / Hot Water |
| Design Pressure | Atmospheric / Pressurized |
| Design Temperature | Ambient to 120°C |
| Manhole | Provided |
| Inlet / Outlet | Hygienic Ferrule / Tri-Clamp Connections |
| Level Indicator | Sight Glass / Level Sensor |
| CIP / SIP | Available (For Pharma) |
| Mounting | Skid Mounted / Leg Mounted |
Design Features
- cGMP & Hygienic Design
- Smooth Internal Surface to Avoid Bacterial Growth
- Orbital Welding
- Leak-proof Construction
- Sanitary Gaskets & Fittings
- Drain Point with Slope Bottom
- Optional Load Cell Integration, Temperature & Level Control Provision
Compliance & Standards
- cGMP
- WHO Guidelines
- FDA / Food Grade Compliance
- ASME / IS Standard Design
- Suitable for Pharma & Food Industry Use
Applications
1. Pharmaceutical Industry
2. Food & Beverage
Advantages
- Hygienic & Contamination-Free Storage
- Uniform Heating & Mixing
- Easily Cleaning & Maintenance
- Robust Construction
- Ready for Automation Integration
